Noark N852896 MCCB EX9MD1B 125A 500V 2 Pole DC Circ Breaker

Noark N852896 MCCB EX9MD1B 125A 500V 2 Pole DC Circuit Breaker, Noark N852896-2P-MCCB 125A/500VDC

Noark Moulded Case High Current DC Circuit Breakers (Non-polarised)

The Ex9MD range of moulded case circuit breakers (MCCB) provide high current breaking capabilities for DC circuits.

Used primarily on battery banks, these MCCBs provide a more serviceable approach to protection than standard NH fuse bases..

Specifications

Noark Series EX9MD1B TM DC125 2P
Poles 2 (250VDC per pole)
Current Rating (A) 125A
Voltage (Max.) 500VDC
Rated Insulation Voltage (VDC) Ui 1000VDC
Rated Breaking Capacity 25kA
Release Technology Thermo Magnetic
Frame Size 2
Frame Rating 250A
IP Rating (All sides/terminals) IP40 / 20
Standards IEC/EN/AS60947-2

Noark MCCB’s are adjustable:

mccb adj icon If the above product is out of stock, you can use the 160A rated N852899 model with the pot switch adjusted to 0.8 to still achieve a 128A rating.

View the Noark MCCB range with all adjustment ratings, or review the Noark MCCB Product Brochure
N20306 TCE21 3P8734 thumb View the suitable Terminal Protector/Shield

Compatible Products:

LabelData
Compatible With:
Suitable For:

$344.49$299.56 Inc GST+ GST

On Backorder

Delivery Estimate: within 1 to 2 weeks. Information on Back-Order cut offs and deliveries.

Specifications:

NameValue
Product Model:Noark N852896-2P-MCCB 125A/500VDC
Technology:
Information Link: Noark N852896-2P-MCCB 125A/500VDC.pdf
Rechargeable / Non-Rechargeable:
Hazardous & DG Class:
(NB IATA Regs may apply)
Manufactured By:Noark Inverter
Original Brand:Noark
Size:125A
Voltage:500V
Capacity:125A
Wattage:
Cell Profile:
Termination:
Weight:
Length:8.16 cm
Width/Diameter:6.2 cm
Height:14 cm
