VE MultiPlus Inverter & SLA/LiFePO4 Chgr 12V 70A-16A PMP122160000

Victron Energy MultiPlus Inverter & SLA/LiFePO4 Charger 12V 1600VA 70A – 16A Transfer Switch PMP122160000, VEICMP-12/1600/70-16

The Multi Inverter Charger is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology and a high-speed AC transfer switch in a single compact enclosure.

Proven reliability
The full bridge plus toroidal transformer topology has proven its reliability over many years.
The inverter is short circuit proof and protected against overheating, whether due to overload or high ambient temperature.

PowerControl – Dealing with limited generator, shore side or grid power (800VA /1200VA)
With the Multi Control Panel a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.

PowerAssist – Boosting the capacity of shore or generator power (800VA /1200VA)
Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery.

High start – up power
Needed to start high inrush loads such as power converters for LED lamps, halogen lamps or electric tools.

Search Mode
When Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode the Multi, when operating in inverter mode, is switched off in case of no load or very low load, and switches on every two seconds for a short period. If the output current exceeds a set level, the inverter will continue to operate. If not, the inverter will shut down again.

Programmable relay
By default, the programmable relay is set as an alarm relay, i.e. the relay will de-energise in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).

Remote on / off / charger on
Three pole connector

This package comes supplied with:

• 12V 1200VA 50A Inverter Charger

Related Products

[products ids=”637130,637201,637053,637219″ per_page=”4″

MultiPlus 500VA – 1200VA manual

INSTALLATION TO NEW ZEALAND STANDARDS REQUIRED This product requires installation to the appropriate New Zealand Standards Various NZ legislations require a Licensed Electrician to install this item – Please consult the NZ Government websites for more information.
